The TL-WR740N is a combined wired/wireless network connection device integrated with internet-sharing router and 4-port switch. The wireless N Router is 802.11b&g compatible based on 802.11n technology and gives you 802.11n performance up to 150Mbps at an even more affordable price. Bordering on 11n and surpassing 11g speed enables high bandwidth consuming applications like video streaming to be more fluid. You can enjoy a high quality experience when video streaming, VoIP, or online gaming wirelessly, with traditional g products was never very practical, from anywhere in your entire home.
TP-LINK TL-WR740N is a high speed solution that compatibles with IEEE 802.11b/g/n. Based on N technology, TL-W740N gives you 802.11n performance up to 150 Mbps at an even more affordable price, 9X the speed and 4x the range of traditional 11g products.
Bordering on conventional 11N and surpassing 11G performance enabling high bandwidth-consuming application, such as video streaming, using VoIP, or online gaming, wirelessly which, with traditional g products was never very practical, from anywhere in your entire home. Enjoy N Power, G Price!
Compatible with WI-FI Protected Setup™ (WPS), TL-WR740N features Quick Security Setup that allows users to almost instantly setup their security simply by pressing the "QSS" button automatically establishing a WPA2 secure connection, which is more secure compared with WEP encryptions. Not only is this faster than normal security setups but more convenient in that you don't need to remember a password!
Allows even novice users to setup the router products without sacrificing any key features, just play the Setup CD to have your network set up quickly & hassle-free.
4 10/100Mbps LAN Ports
1 10/100Mbps WAN Port
Quick Setup Security Button (WPS Compatible)
Power On/Off Button
|External Power Supply||9VDC / 0.6A|
|Wireless Standards||IEEE 802.11n*, IEEE 802.11g, IEEE 802.11b|
|Antenna||5dBi Fixed Omni Directional|
|Dimensions ( W x D x H )||6.9 x 4.6 x 1.3 in. (174 x 118 x 33 mm)|
11n: Up to 150Mbps(dynamic)
11g: Up to 54Mbps(dynamic)
11b: Up to 11Mbps(dynamic)
130M: -68dBm@10% PER
108M: -68dBm@10% PER
54M: -68dBm@10% PER
11M: -85dBm@8% PER
6M: -88dBm@10% PER
1M: -90dBm@8% PER
|Wireless Functions||Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics|
|Wireless Security||64/128/152-bit WEP / WPA / WPA2,WPA-PSK / WPA2-PSK|
Dynamic IP/Static IP/PPPoE/
PPTP(Dual Access)/L2TP(Dual Access)/BigPond
Server, Client, DHCP Client List,
|Quality of Service||WMM, Bandwidth Control|
|Port Forwarding||Virtual Server,Port Triggering, UPnP, DMZ|
|Dynamic DNS||DynDns, Comexe, NO-IP|
|VPN Pass-Through||PPTP, L2TP, IPSec (ESP Head)|
|Access Control||Parental Control, Local Management Control, Host List, Access Schedule, Rule Management|
DoS, SPI Firewall
IP Address Filter/MAC Address Filter/Domain Filter
IP and MAC Address Binding
OEM Cartridge. OEM stands for the Original Equipment Manufacturer. If you own a Brother printer for instance, then the OEM cartridge is manufactured by Brother.
Compatible Cartridge. A compatible toner cartridge is made by a third party manufacturer and is made up of all new compatible parts. It has a similar quality to an OEM cartridge, but the price is much cheaper than the OEMs.
Remanufactured Cartridge. A remanufactured cartridge is when a third party manufacturer recycles an original OEM cartridge, disassembles it, tests and replaces any worn parts, fills it with ink or toner, and re-assembles.
Compatible and remanufactured cartridges will print at least the same page yield than the OEMs, and backed by our 1 year Guarantee.
Click anywhere to close this popup
Page Yield is an approximation of the number of standard pages that can be printed with one cartridge, usually measured at 5% page coverage.
Our new compatible and remanufactured cartridges will print at least the same amount page yield which is suggested from the original (OEM) cartridges.
Click anywhere to close this popup
|Certification||CE, FCC, RoHS|
1 fixed omni directional antennas
Power supply unit
Quick Installation Guide
|System Requirements||Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7, MAC® OS, NetWare®, UNIX® or Linux.|
Operating Temperature: 0℃~40℃ (32℉~104℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
